Dimensional Tolerances for Steel Castings
Dimensional Tolerances
Dimensional tolerance and size are the most important factors in deciding if investment casting is the right solution for your project. Tolerance is set on by the shape and the size of a part and includes both geometric and linear factors such as :
- Length
- Concentricity
- Roundness
- Parallelism
- Flatness
- Straightness
- Angularity
- Perpendicularity
So, What Dimensional Tolerances Can Be Achieved By Using Investment Casting?
The main factors for determining geometric and linear tolerances are size and shape. For projects that require strict tolerances, Investment casting is an excellent option as it produces parts with great accuracy and repeatability. General parameters for linear investment casting tolerances are shown below :
Advantage Of Using Investment Casting
- Flexible Design
- Less Waste, Strong Manufacturing Cost
- Tighter Tolerance (More Precise)
- Excellent and smooth surface finish
- Reduce the need for secondary machining.
- Wide selection of cast metals and alloys
Why Should You Choose Zenith?
- Engineering, With 20 years of experience in Lostwax Casting, we are experts in casting any kind of products and materials. Updating knowledge is a must as part of our Engineering team’s daily workload.
- Quality Focus, Our focus is Zero defects at the customer site.With ISO 9001:2015, ISO 13485:2016, CE Marking and PED 2014/68/EU Annex. I,4.3 & AD 2000-W0 certified, we have a system to control every production step to get the required quality that customer needs,
- High Capacity, Our capacity a month can cover 120 tons with available induction furnaces range from 100kg, 150kg, and 250 kg.We also have 1 dedicated line for medical products (zenmed+)
- IT Utilize System, With every process is managed using a cloud system, the information flow is very quick and accessible everywhere & anytime.We also enable Extranet for customers to check their PO progress and related information and documents.
- Lean Manufacturing, By applying Lean Manufacturing, every process steps is Visual Controlled and Every Waste is identified and controlled using Continuous Improvement/Kaizen.
- Health, Safety, & CRS, By having certified for ISO 45001:2018 and ISO 14001:2015, We are committed to concern with our People Health, Safety & Environment. We are also a permanent donator for Indonesia Cancer Foundation and supporting Orphans nearby the Factory.
